Overseas Steelage are suppling & exporting superior quality variety of flanges. The Flanges offered by us find their application in various industrial processes. Flanges of size upto 60 inches can be provided from ready stock or on make to order basis. Can offer Slip-On flanges, Weldneck flanges, Socketweld flanges, Lapjoint flanges, Threaded flanges, Blind flanges, Long weldneck flanges, Spectacle Blind flanges in carbon steel, stainless steel, alloy steel, nickel alloys, duplex steel, etc.
Flanges
| Specifications: | |
| Size: |
1/2" (15mm) NB TO 24" (600mm) NB (ABOVE 24" NB MAKE TO ORDER BASIS) |
| Nominal Pressure Range: |
150# - 2500# |
| Schedule: |
5S, 10S, 10, 20, 40S, 40, STD, 60, 80S, 80, XS, 100, 120, 140, 160, and XXS |
| Type: |
Weld neck, Slip-On, Socket weld, Lap Joint, Threaded, Blind, Orifice, Long Weld Neck, Spectacle Blinds |
| Face Type: |
Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ) |
| Grades Available: |
CARBON STEEL: ASTM A 105, LF 2, LF 3
ALLOY STEEL: ASTM A182 GR. F1, F 5, F 9, F 11, F 22, F 91
STAINLESS STEEL: ASTM A182 GR. 304/304L, 316/316L, 310, 347, 321, 904L
NON FERROUS METALS: COPPER, HASTELLOY C 276, INCONEL 600/625/825, BRASS, MONEL 400/500
|
| Flange Standards: |
ANSI : ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48
DIN : DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673
B.S: BS4504, BS4504, BS1560, BS10
|
