| Specifications: |
Size:
|
1/2" (15mm) NB TO 24" (600mm) NB (ABOVE 24" NB MAKE TO ORDER BASIS)
|
Nominal Pressure Range:
|
150# - 2500#
|
Schedule:
|
5S, 10S, 10, 20, 40S, 40, STD, 60, 80S, 80, XS, 100, 120, 140, 160, and XXS
|
Face Type:
|
Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
|
Grades Available:
|
CARBON STEEL: ASTM A 105, LF 2, LF 3
ALLOY STEEL: ASTM A182 GR. F1, F 5, F 9, F 11, F 22, F 91
STAINLESS STEEL: ASTM A182 GR. 304/304L, 316/316L, 310, 347, 321, 904L
NON FERROUS METALS: COPPER, HASTELLOY C 276, INCONEL 600/625/825, BRASS, MONEL 400/500 ,TITANIUM, TANTALUM, BRONZE, ALUMINIUM, HIGH SPEED STEEL, ZINC, LEAD
|
Flange Standards:
|
ANSI : ANSI B16.5, ANSI B16.47, MSS SP44, ANSI B16.36, ANSI B16.48
DIN : DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636, DIN2637, DIN2638, DIN2673
B.S: BS4504, BS4504, BS1560, BS10
|
|
